A long-radius high-pressure elbow designed for frac pump discharge and treating iron systems. Provides smooth directional change with minimized pressure drop and erosion. Equipped with Fig 1502 male/female union ends for fast rig-up operations.
Long radius elbow is a high-pressure elbow with a long sweep design, which is used for fracturing, acidizing, cementing and high-pressure transportation systems in the oil & gas industry.
Compared with short-radius elbows, it has less flow resistance, low pressure loss and higher erosion resistance.
Key Features
-Large arc radius reduces turbulence
-Smooth flow path reduces erosion
-Ideal for pump discharge connections
-Commonly paired with 1502 hammer unions
-Suitable for 15000psi working pressure systems
-Used heavily in frac pumps/manifolds/flowlines
Typical specifications
Size: 2”, 3”, 4”
Pressure rating: 15000psi
Standard: Fig1502 hammer union
Radius: Long radius(LR)
Material: Alloy steel, heat treated
Application: Pump discharge, frac iron, manifolds
